Diamond Audioworks – MEGA – Isolation Transformer

Product Description

Diamond Audioworks MEGA Isolation Transformer

The Diamond Audioworks MEGA Isolation Transformer is a high-capacity power isolation solution engineered to deliver exceptionally clean and stable power to high-end audio systems. Designed around a precision Japanese C-Core transformer, the MEGA provides complete electrical isolation from the incoming mains supply, dramatically reducing noise, interference, and voltage instability that can degrade audio performance.

In modern homes, electrical pollution is unavoidable. Switch-mode power supplies, appliances, LED lighting, and networking equipment continuously inject noise into the mains supply. This contamination raises the noise floor of sensitive audio equipment and can mask musical detail, reduce dynamics, and compromise system transparency.

The MEGA solves this problem by using a true 1:1 isolation transformer topology, separating the primary and secondary circuits through magnetic coupling. Because there is no direct electrical connection between input and output, high-frequency noise, ground contamination, and electrical interference cannot pass through the transformer. The result is a significantly cleaner power source for your audio system.

At the heart of the design is a Japanese C-Core transformer wound with a special 5mm flat copper conductor, chosen for its superior current delivery, efficiency, and low electromagnetic leakage. This allows the unit to deliver 3000 watts (3kVA) of continuous clean power, making it suitable for demanding high-end systems including power amplifiers, digital front ends, and analogue sources.

The transformer is housed inside a 10mm thick acrylic enclosure, chosen not only for its strength and durability but also to ensure maximum electrical safety while providing visual access to the transformer architecture. Internal wiring uses 4mm single-core stranded copper conductors to maintain excellent current flow throughout the power path.

To further enhance performance and protection, the MEGA incorporates RFI and EFI filtering circuitry, reducing radio frequency interference and electrical noise entering the system. The unit features high-quality Furutech power inlets, three copper power sockets providing six outlets, and a robust Mitsubishi power switch for reliable operation.

In addition to power purification, the MEGA includes an advanced voltage protection system designed to safeguard valuable audio equipment:

* Automatically shuts down if voltage drops below 195V
* Automatically shuts down if voltage exceeds 250V
* Restarts automatically when voltage stabilises above 200V with a 30-second delay
* Protects against power surges, overvoltage, and lightning strikes

These protection mechanisms ensure your system remains protected from unstable power conditions while maintaining optimal audio performance.

With a total weight of approximately 50kg, the Diamond Audioworks MEGA Isolation Transformer is built to deliver extreme stability, high current capability, and long-term reliability.

When installed in a high-performance system, listeners typically experience:

* Lower noise floor
* Improved dynamics and transient response
* Greater instrument separation
* Tighter bass control
* More natural and effortless musical presentation

For serious audiophiles, clean power is the foundation of system performance. The Diamond Audioworks MEGA Isolation Transformer provides the stability, protection, and sonic improvements required to unlock the full potential of your equipment.
